Nozzle Module/ All Metal Hotend
Release date:2020-11-25 16:19:11
Nozzle Module/ All Metal Hotend
Selling Point:
The pure metal nozzle, no need of PTFE, effectively reduce the probability of plug, and support higher temperature printing (up to 280℃) to increase material compatibility. Product Features: Smart leveling, optimizes traditional manual leveling, wifi connection,real-time monitoring. Power-off resume: Continue printing after power is resumed. Full metal quick replace nozzle, compatible with multiple filaments. Alarm on filament breaking or filament run-out resume. Abnormal heat protection Midway filament change, press”Midway refueling” is easy to change filament.
Description:
Machine size: 408×404×535 mm
Printing size: 200×200×300 mm
Product weight: 22kg
Layer thickness: 0.05-0.30mm
Precision: ±0.1-0.3mm
Printing speed: Suggest 40-60mm/s; Max 300mm/s
Forming principle: FDM Nozzle
Diameter: Standard 0.4mm ( 0.8mm optional)
Nozzle structure: Single
Printing mode: Single color model
Printing material: PLA/ABS/HIPS/PHA/PETG/PA/PC
Filament diameter: 1.75mm
Slicing software: CURA(MakerPi program)
Language support: Chinese/English
Format: stl; Gcode; obj; dae; amf; bmp; jpg
XYZ accuracy: XY axis 0.0128mm, Y axis 0.0025mm
Hot bed temperature: 0-120℃
Nozzle temperature: 0-280℃
LCD: 4.3 inches color touch scree
Input voltage: 110 V/220 V
Output voltage: 24 V
Power: 100 W/200 W
Certification: CE,FCC,ROHS
